Trend DWS/HG/SET Diamond Honing Guide Set
The Trend DWS/HG/SET diamond honing guide set will ensure that you maintain the correct angle on chisels and plane irons. The setting device is preset for 25 degree, 30 degree, 35 degree and 40 degree angles
Features:
- Ensures correct primary angle is maintained on bevel edge chisels and plane irons when used with diamond whetstone
- Precision roller with alloy body which self-centre clamps bevel edge chisels from 3/8 inch (10mm) to 1-1/4 (32mm) and plane irons up to 2-3/8 inch (60.3mm) wide. Maximum tool thickness 7mm
- Positive location for roller and blade
- Adjustable stop for setting blade angle
- Use with 63mm (2 1/2 inch) wide x 178mm (7 inch) long bench stones or workshop stones
- Not for use with Firmer chisels or short blade (Butt) chisels
- Warranty: 12 months
Comes With:
- 1 x Diamond honing guide
- 1 x Diamond honing guide setting device
Specification:
- Chisel blade width min.:10 mm
- Chisel blade width max.:32 mm
- Chisel blade thickness max.:7 mm
- Chisel blade length min.75 mm*
- Plane blade width max.:60.3 mm
- Angle:25 deg, 30 deg, 35 deg & 40 deg
- *at 25 deg
- Nett Weight: 0.407 Kg
- Packaged Size: 160x95x40mm
