The Sealey YK20F Hydraulic Press is fitted with a ram pressure gauge
The Sealey YK20F is a 20tonne Hydraulic Press with a steel frame construction and a side-mounted hydraulic pump unit. Featuring a sliding hydraulic ram assembly giving 400mm of lateral travel for off-centre pressing applications. Supplied with flat pressing plate/V-blocks.
Features:
- Fitted with ram pressure gauge
- Supplied with flat pressing plate/V-blocks
- Steel frame construction with side-mounted hydraulic pump unit
- Sliding hydraulic ram assembly giving 400mm of lateral travel for off-centre pressing applications
Specification:
- Weight: 94kg
- Ram ∅: 50mm
- Mounting: Floor
- Type: Hydraulic
- Capacity: 20 tonne
- Ram Stroke: 185mm
- Gauge Included: Yes
- Table Aperture: 105mm
- Overall Height: 1810mm
- Lateral Ram Travel: 400mm
- Working Table Depth:205mm
- Working Table Width: 550mm
- Minimum Height - Ram to Table: 65mm
- Maximum Height - Ram to Table: 1025mm
