The Sealey ES601 Engine Support Beam with a 360° adjustable rotating cross beam
The Sealey ES601 is an engine support beam designed to support and accurately position engines during maintenance operations such as replacing anti-vibration mountings and certain body panels. This model has the additional advantage of a 360° adjustable rotating cross beam to enable a greater range of support options when in use.
Features:
- Also used as an aid for the removal of gearboxes and transmissions
- Beams supported on rubber feet and fine adjustment control is obtained by using screw/hook mechanisms
- This model has the additional advantage of a 360° adjustable rotating cross beam to enable a greater range of support options when in use
- Designed to support and accurately position engines during maintenance operations such as replacing anti-vibration mountings and certain body panels
Specification:
- Weight: 15kg
- Model No: ES601
- Maximum Capacity: 500kg
- Screw Hook Lengths: 410/320mm
- Main Beam Minimum Width: 140mm
- Cross Beam Minimum Width: 140mm
- Cross Beam Maximum Width: 810mm
- Main Beam Maximum Width: 1400mm
