The Sealey CB5000 Chain Block allows use where headroom is limited
The Sealey CB5000 is a 3m Chain Block with a 5-tonne capacity, fitted with heat-treated and ground, triple-spur geared shaft and pinion. All chains are manufactured from hardened alloy material and load hooks feature safety latches. Also includes a mechanical load brake for extra safety.
Features:
- Also includes a mechanical load brake for extra safety
- Compact gear housing allows use where headroom is limited
- Fitted with heat-treated and ground, triple-spur geared shaft and pinion
- All chains are manufactured from hardened alloy material and load hooks feature safety latches
Specification:
- Weight: 43kg
- Standard Lift: 3m
- Test Load: 7500kg
- Model No: CB5000
- Load Chain ∅: 10mm
- Head Room: 588mm
- Overall Width: 186mm
- Hook Aperture: 50mm
- Overall Depth: 253mm
- Pulling Effort: 42.22kgf
- Safe Working Load: 5000kg
- Maximum Hook Capacity ∅: 65mm
