Metabo CS23-355 Metal Chop Saw complete with cutting disc
The NEW CS 23 - 355 is powerful 2,300 W Metal cutting chop saw. Designed for use with abrasive wheels this machine will produce precise cuts in steel, non-ferrous metals, iron and cast profiles. Coupled with high performance statistics this machine has been designed with ease of use and transportation in mind.
Features:
- For single phase alternating current
- Especially suitable for the fast, precise cutting of steel, non-ferrous metals, iron and cast profile
- Motor and gear with ball bearing and designed for high loads
- Spindle lock for easy disc change
- Quick clamping device with variable mitre conversion up to 45° on both sides
- Easy to transport due to built-in handle and locking device
- Swivelling blade guard
- Adjustable spark guide plate
- Bottom access guard
- Adjustable depth guide
Comes with:
- Open-ended ring spanner
- Inner support flange
- Flange nut
- Metal Cutting Blade
Please note 110V model is 1650 watt input power
Specification:
- Disc diameter: 355 mm
- Bit retainer, diameter: 25.4 mm
- No load speed: 4,000 /min
- Rated input power: (240V is 2,300 W and 110V is 1,650W
- Maximum cutting dimension: Bar steels 65 mm, Pipes 125 mm, Shaped steels 115 x 130 mm
- Maximum opening of vice jaws: 238 mm
- Dimensions of the base plate: 468 x 282 mm
- Transport height: 400 mm
- Weight: 16.9 kg
SKU: MET-602335390-CS23-355-110V
