Cut large construction timbers up to 110 x 303mm with this electric mitre saw
The Dewalt DWS780 mitre saw is the evolution of the highly popular DW718XPS and features increased capacity, a brighter XPS system, increased portability and better dust extraction. With massive cutting capability, this Dewalt mitre saw performs in both small profiles and large construction timbers up to 110 x 303 mm. The XPS shadow line cut indicator provides accurate and fast alignment of the blade while lighting the job in hand for faster work rate. Overall a great piece of high-quality kit.
Features:
- Outstanding cutting performance in both small profiles and large construction timbers up to 110 x 303 mm
- XPS Shadow line cut indicator provides fast accurate alignment of the blade while illuminating the workpiece for increased productivity no adjustment required
- Heavy-duty durability with the ability to fully adjust your machine to maintain accuracy over the life fo the tool.
- New quick release bevel stop setting provides an accurate and simple setting of bevel angles up to 49° left and right
- Easy to use mitre and bevel controls making the tool fast and simple to change from one set up to another
- Cam action mitre lock function makes mitre setting faster and easier allowing the user to quickly adjust angles between 0° - 50° left and 0° - 60° right
- Long-life Accuracy in Table and Fence Design
- The large dual sliding fence gives maximum support in large material cuts at any angle or combination of angles
- Linear horizontal rails utilise bronze guides to provide maximum precision when cutting materials up to 345 mm wide
- Compact and lightweight design characteristics deliver a saw with enormous capacity which is easy to transport around the job site
- Outstanding dust control and deflection away from cutting area
- Electronic speed control for adjusting cutting speed when cutting materials other than wood
- The innovative grooving stop allows the adjustment of the cutting depth for grooving and rebating applications
Comes with:
- High Quality 60 tooth blade
- Blade spanner
- Dust bag
- Material Clamp
Specification:
- Power Input: 1675 Watts
- Power Output: 960 Watt
- Blade Speed: 1900 - 3800 rpm
- Blade Diameter: 305 mm
- Blade Bore: 30 mm
- Bevel Capacity: 49/49 °
- Mitre Capacity [right/left]: 60/50 °
- Cutting Capacity at 90°/45° (W x H): 211 x 112 mm
- Cutting Capacity at 90°/90° (W x H): 303 x110 mm
- Cutting Capacity at 90°/90° (W x H): 345 x 76 mm
- Cutting Capacity at 45°/90° (W x H): 268 x 63 mm
- Cutting Capacity at 45°/90° (W x H): 345 x 44 mm
- Cutting Capacity at 90°/45° (W x H): 244 x 76 mm
- Max. Cutting Capacity at 45°/45°: 212 x 76 mm
- Max. Depth of Cut [Saws]: 170 mm
- Weight: 24.8 kg
- Depth: 470 mm
- Length: 770 mm
- Height: 396 mm
- Hand/Arm Vibration - Cutting Wood: <2.5 m/s²
- Uncertainty K 1 (Vibration): 1.5 m/s²
- Sound Power: 100 dB(A)
- Sound Power Uncertainty: 3 dB(A)
- Sound Pressure: 93 dB(A)
- Sound Pressure Uncertainty: 3 dB(A)
SKU: DEW-DWS780-240V
